Danfoss ECL Comfort 210 komplektas
- Kit contents: ECL 210 controller + application key (A214/A217/A230 depending on revision)
- Circuits: 1 heating + DHW (per key)
- Power supply: 230 V AC
- Sensors: Pt1000 (ordered separately unless already in system)
Applications
Single-loop substation control — small multi-unit residential buildings, single-family houses, small commercial premises. The application key is preconfigured for a standard district-heating substation schematic with DHW.
Technical specifications
| Parameter | Value |
|---|---|
| Code | 087H3104 |
| Type | Electronic controller kit with key |
| Circuits | 1 heating + DHW |
| Power supply | 230 V AC ±10 %, 50/60 Hz |
| Ambient temperature | 0 → +55 °C |
| Display | Graphical, multilingual |
| Communication | Modbus RTU (basic) |
| Sensor type | Pt1000 (ESM/ESMT series) |
| Protection class | IP 41 |
Notes for the designer
The bundled application key matches a standard district-heating schematic with one heating circuit. Non-standard projects (solar collectors, thermal storage) require a different key or ECL 310. Delivery across the EU.
When to choose the ECL 210 kit
- Single-loop building — no need for two independent heating circuits
- Simple BMS integration — Modbus RTU is enough
- Standard DH schematic with DHW
- Ready-to-install solution preferred over separate components
B2B delivery and logistics
- Delivery across the EU (from warehouse in Vilnius, LT)
- Competitive B2B pricing for projects
- 30-day payment terms for companies (per contract)
- Free technical consultation on sensors and installation
Official Danfoss catalog: store.danfoss.com/087H3104
FAQ
Are sensors included?
No. Only the controller and key are supplied. Sensors (outdoor ESMT, immersion ESMU) are ordered separately — they are often already present after the initial installation.
Which key is included?
Typically A230 or an equivalent single-heating + DHW key. Confirm the actual revision with us before ordering — Danfoss has revised article numbers over the years.
Can the ECL 210 kit key be used in an ECL 310?
No. A2xx keys work only in ECL 210. ECL 310 requires A3xx keys.
