High-flow DHW substations: multi-unit buildings, hotels, residential complexes, sports centres. Supports larger flows without excessive Δp across the valve. Delivery across the EU.
| Parameter | Value |
|---|---|
| Code | 003N5113 |
| Type | Self-acting thermostatic valve |
| DN | 25 |
| Kvs | 5.5 m³/h |
| Connection | G 1 1/4" male thread |
| Setting range | 20-60 °C |
| PN | 16 bar |
| Max media temperature | 130 °C |
| Capillary tube | 2 m |
| Body material | Dezincification-resistant (DZR) brass (BS 2872 / CZ132) |
Size is selected from kv = Q / √Δp (Δp across the valve): choose the smallest valve whose Kvs is not lower than the calculated kv. AVTB 25 (Kvs 5.5 m³/h) is the largest size of the series.
Danfoss manufacturer catalog: store.danfoss.com/003N5113
The largest AVTB size is DN 25 (Kvs 5.5 m³/h); larger flows need other solutions.
If the sensor is installed in a sensor pocket (ordered separately; for the 20–60 °C sensor with M14×1 / R½ connection, e.g. 013U0290), it can be removed without depressurising the system.
